| Geometry |
| Size |
XS |
S |
M |
L |
XL |
| Seat Tube Length (cm) |
43.5 |
45.5 |
47.5 |
49.5 |
52 |
| Top Tube Length (cm) |
49.3 |
51.5 |
52.5 |
54.5 |
55.5 |
| Head Tube Length (cm) |
10 |
13.5 |
11.4 |
14.5 |
16.5 |
| Head Tube Angle |
71.0 |
71.5 |
72.0 |
73.0 |
73.0 |
| Seat Tube Angle |
73.5 |
73.5 |
73.0 |
73.0 |
73.0 |
| Chainstay Length (cm) |
41.0 |
41.0 |
42.0 |
42.0 |
42.0 |
| Wheelbase (cm) |
95.1 |
97.0 |
97.7 |
98.3 |
99.3 |
| Standover Height (cm) |
67.7 |
70.3 |
72.9 |
75.6 |
77.7 |
| Front Center (cm) |
54.6 |
56.6 |
56.8 |
57.4 |
58.4 |
| BB Drop (cm) |
5.0 |
5.0 |
7.3 |
7.3 |
7.3 |
| Fork Rake (mm) |
45.0 |
45.0 |
50.0 |
45.0 |
45.0 |
| Frame Weight (grams) |
1300 |
1330 |
1340 |
1390 |
1440 |
| Frame Weight (lbs) |
2.86 |
2.93 |
2.95 |
3.06 |
3.17 |
| Wheel Size |
650C |
650C |
700C |
700C |
700C |
|
